Channel Resolution Accuracy Setting of Non-Sequential Field Tracing

Abstract

Non-sequential analysis of optical setups, especially the analysis of system with waveguides and coupling gratings, is of great importance. Non-sequential field tracing is done with two steps in VirtualLab Fusion. Firstly, according to an adjustable accuracy factor, the light path through the system is detected. Secondly, light fields are traced along these found paths. The light path detecting accuracy can be controlled by the Channel Resolution Accuracy in VirtualLab Fusion.

VirtualLab Fusion Configuration

  • VirtualLab Fusion VirtualLab Fusion
  • AR VR MR Package AR VR MR Package
  • Grating Package Grating Package
