Non-Sequential Ray Tracing Analysis of Glass Plate

For many optical systems, a full analysis of them must include the multiple reflections between surfaces and components. By using the non-sequential tracing technique in VirtualLab Fusion, the ray tracing analysis of a glass plate is performed. With the channel concept, one can flexibly switch between sequential and non-sequential tracing and control the region of interests. Examples on non-sequential ray tracing within the glass plate, as well as between the lens surface and the glass plate are presented.
