The Detector Revolution

The all new version 2023.1 of the fast physical optics modeling and design software has finally arrived. And with it come lots of new features. One we want to particularly highlight is the new Universal Detector and the evolution it brings with it in terms of detector modeling. This new element replaces the Electromagnetic Field Detector and like its predecessor, can display any field component in x- and k-domain. Furthermore, with its inclusion of customizable add-ons, this detector allows for utmost flexibility, as any physical value can be calculated from the provided field information, directly.

Hence, for this week’s newsletter, we present you an in-depth look into the Universal Detector, as well as an application example in the form of an aspherical focusing system. In this optical setup we display the field (including the phase distribution), calculate the energy density of the focus and investigate the change in the spot size as the beam travels through its focal region. With our new detector concept, this all can be carried out with the same detector.

Universal Detector

The Universal Detector is the most versatile tool to evaluate and output any information of an electromagnetic field in VirtualLab Fusion.

Focus Investigation behind Aspherical Lens

A laser diode with asymmetric divergence and astigmatism is first collimated and then focused. Evolution of the field in the focal region is investigated in detail.

Free Webinar

This Week, Our Webinar Series on the New Virtuallab Fusion 2023 Comes to an End.

In three exciting webinars you will learn about the new features, its theoretical foundations, and its practical applications.

23 January 2023 | 14:00 CET - An Overview

25 January 2023 | 14:00 CET - Theory and Practice

26 January 2023 | 14:00 CET - The Detector Revolution

Register now!
